Super Duplex Steel Forging in Houston
Super Duplex Steel Forging, Super Duplex Steel Forging in Houston, Super Duplex Steel Alloy Forging, Super Duplex Steel Flat Forging in Houston, ASTM A182 Super Duplex Steel Forging Stockist in Houston, Open Die Forging, Closed Die Forging, Super Duplex Steel Forging Supplier in Houston
Renine Metalloys is a reliable Super Duplex Steel Forging exporter in Houston. We supply high-quality forgings that meet DIN, ASTM, and BS international standards . Known for strength and corrosion resistance, super duplex steel forgings are used in demanding environments, from marine to chemical industries.
We offer these Forging in a wide range of sizes and shapes. Our forging methods include impression die drop forging, closed die forging, press forging, upset forging, compression forging, swaging, rotary forging, and roll forging. Each piece is crafted to meet the exact needs of your project. For simple forms or complex shapes, we deliver consistent performance and durability.
The product range includes forged bars, shafts, rings, discs, gear blanks, blocks, hollows, hollow bars, billets, and ingots. These are produced to ASTM A182 and ASME SA182 specifications. Forging is carried out at temperatures between 1000°C and 1200°C to ensure optimal mechanical properties and structural integrity. Every part is designed to handle pressure, impact and corrosion in extreme settings. Our super duplex steel forging is available in grade Super Duplex 2507 to ensure durable performance.
For ensuring quality, all our products go through testing. This includes hardness test, tensile test, shell pressure tests, impact test, material inspection, and visual inspection. We also supply complete documentation like Raw Materials Certificate, EN 10204/3.1B, and a 100% Radiography Test Report. We are ISO certified, our processes are optimized, and we understand the importance of timely delivery. Being a super duplex dteel forging exporter in Houston, we ensure that our products are delivered to you quickly without any compromise on quality.
Super Duplex Steel Forging Specification
| Specifications | Details |
| Specifications | ASTM A182, ASME SA182 |
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
Reach Out – We’re Happy to Help!
Feel Free to connect with us. Our team is ready for a handful of support
Types of Super Duplex Steel Forging in Houston
Forged Billets
Super Duplex Steel Forged Billets in Houston
Forged Shaft
Super Duplex Steel Forged Shaft in Houston
Forged Block
Super Duplex Steel Forged Block in Houston
Forged Flat Bars
Super Duplex Steel Forged Flat Bar in Houston
Forged Disc
Super Duplex Steel Forged Disc in Houston
Forged Ring
Super Duplex Steel Forged Ring in Houston
Super Duplex Steel Forging Equivalents Grades in Houston
| Standard | Werkstoff Nr. | UNS |
| Super Duplex S32750 | 1.4410 | S32750 |
| Super Duplex S32760 | 1.4501 | S32760 |
Super Duplex Steel Forging Chemical Composition In Houston
| Grade | C ≤ | Mn ≤ | P ≤ | S ≤ | Si ≤ | Ni | Cr | Mo | N | Cu |
| S32750 | 0.03 | 1.20 | 0.035 | 0.02 | 0.80 | 6.0–8.0 | 24.0–26.0 | 3.0–5.0 | 0.24–0.32 | 0.5 |
| S32760 | 0.05 | 1.00 | 0.03 | 0.01 | 1.00 | 6.0–8.0 | 24.0–26.0 | 3.0–4.0 | 0.20–0.30 | 0.50–1.00 |
Super Duplex Steel Forging Mechanical Properties In Houston
| Grade | Tensile Strength, min ksi [MPa] | Yield Strength, min ksi [MPa] | Elongation, % (min) | Hardness, HB (max) |
| S32750 | 116 [800] | 80 [550] | 15 | 300 |
| S32760 | 109 [750] | 80 [550] | 25 | 300 |
