Stainless steel angles are an incredibly versatile and reliable material used in a variety of industries.SS Angle are strong, light weight and durable, making them ideal for a range of applications. Stainless Steel Angles are commonly used in structural engineering and building projects because they can be cut to precise sizes with minimal waste. Steel Angles Bars also used in industrial construction applications such as manufacturing plants, warehouses, and storage facilities. In addition to these uses, stainless steel angles are also often used for decorative purposes in residential buildings or commercial spaces like malls and office buildings.
Stainless Steel Angles, SS Angles, Steel Angles Bars, Stainless Steel 304 Steel Bar Angles Exporters, SUS 304L SS Equal Angle, AISI Steel 304H Unequal Leg Angle Suppliers, SS Angle Weight Chart, SS Metal Angles, ASTM A276 SS 310 Equal Leg Angle Manufactures, Stainless Steel Angle manufacturer, ASME SA479 SS 310S Unequal Angle, SS Angle Price, 316 Austenitic Stainless Steel Hot Rolled Steel Angle Stockholders in Mumbai India
Stainless Steel Angles come in two main types: equal or unequal angle bars. Equal angle bars have two legs that measure the same size while unequal angle bars have two legs with different sizes. The most common shape is the right-angle bar which is 90 degrees in size. Other shapes include acute-angle bars (less than 90 degrees) and obtuse-angle bars (greater than 90 degrees). Different types of products are available, such as Super Duplex Steel UNS S32750 Forged Fittings, Super Duplex Steel UNS S32750 Round Bars , etc.
Stainless Steel 316L L Angle Stockists, stainless steel angle price, SS 316H T Angle Dealer, SS 316TI Hot Rolled Angle Shape, SS I Angle, 317 Stainless Steel Structural Angles, polished stainless steel angle, SS 317L Structural Steel Angles Bars Dealers in India, angle stainless steel, SS Angle Latest Price, SS 321 Structural Steel Equal Angle Forged Round Bars Distributors in Mumbai.
Stainless Steel Angle
Aside from being strong, lightweight and durable, there are many other advantages to using stainless steel angles including its resistance to corrosion, heat resistance, nonmagnetic properties and effectiveness. 317 Stainless Steel Structural Angles come in a variety of grades which means anyone can choose one that meets the specific needs based on strength requirements or budget limitations without sacrificing quality or performance. Stainless Steel Fasteners, Stainless Steel 304 Flanges and many more grades are also available.
Stainless Steel 316L Angle is a more common option in outdoor, marine, and industrial applications due to its corrosion resistance, whereas Stainless Steel 304L Angle is often used in indoor applications where the material will not be exposed to an excessive degree of corrosion. Stainless Steel Angles are available in different sizes and shapes as per the client's requirements.
Stainless Steel Angle Sizes, Stainless Steel Angle Stock, 316 Stainless Steel Angle, Polished Stainless Steel Angle, Stainless Steel Angle Sizes Chart, 304 Stainless Steel Angle, 304 Stainless Steel Angle Sizes, 316 Stainless Steel Angle Sizes, Unequal Stainless Steel Angles, SS 304 Equal Angle Weight Chart, Stainless Steel 304 Unequal Angle Sizes, 316 Stainless Steel Equal Angle, 316 Stainless Steel Unequal Angle Price List
What is the composition of Stainless Steel Angle?
Stainless Steel Angle is composed of a combination of iron and at least 10.5% chromium, which gives it the properties of stainless steel such as corrosion resistance and durability.
What are the common applications of Stainless Steel Angle?
SS Angle is commonly used in the construction industry, as well as in the manufacture of products such as brackets, bracing, and frames. Its corrosion resistance makes it ideal for use in marine and food processing environments.
What is the temperature range of stainless steel angles?
Stainless Steel Angles can withstand temperatures up to 1500F (816C) in intermittent service and 1650F (899C) in continuous service.
SS 321H Structural Unequal Angle Traders, ASME SA276 Stainless Steel 347 Structural Steel Unequal Leg Angle, Stainless Steel 347H Structural Equal Leg Angle Stockyards, ASTM A479 SS 410 Hot Rolled Structural Steel Angle, SS 446 Structural Steel L Angle Suppliers in Mumbai, Stainless Steel 904L Structural T Angle, Structural 304 Hot Rolled Angle Shape Exporters
Stainless Steel Angle Specification
Standard : ASME, ASTM, EN, BS, GB, DIN, JIS, etc
Size : 3/4″ THRU 8″
Thickness : 1/8″ thru 5/8″
Type : Stuctural Steel Angle, Bars, Equal, Unequal, L, T, Hot Rolled
Stainless Steel Grades : 304/304L/304H/310S/316/316L/316H/316TI/317/317L/321/321H/904L
Get QuoteMechanical Properties of Stainless Steel Angle
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Chemical Properties of SS Angle
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni |
|---|---|---|---|---|---|---|---|---|
| Stainless 304 | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 18 – 20 | – | 8 – 11 |
| Stainless 304L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.03 max | 18 – 20 | - | 8 – 13 |
| Stainless 316 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 - 18.00 | 2.00 - 3.00 | 11.00 - 14.00 |
| Stainless 316L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 1.0 max | 16.00 - 18.00 | 16.00 - 18.00 | 10.00 - 14.00 |
Size Chart of Stainless Steel Angle
| Size in Inches | Est. Weight per Ft. Lbs. | Est. Weight per 20' Bar |
|---|---|---|
| 3/4 x 3/4 x 1/8 | 0.59 | 11.80 |
| 1 x 1 x 1/8 | 0.80 | 16.00 |
| 1 x 1 x 3/16 | 1.16 | 23.20 |
| 1 x 1 x 1/4 | 1.49 | 29.80 |
| 1-1/4 x 1-1/4 x 1/8 | 1.01 | 20.20 |
| 1-1/4 x 1-1/4 x 3/16 | 1.48 | 29.60 |
| 1-1/4 x 1-1/4 x 1/4 | 1.92 | 38.40 |
| 1-1/2 x 1-1/2 x 1/8 | 1.23 | 24.60 |
| 1-1/2 x 1-1/2 x 3/16 | 1.80 | 36.00 |
| 1-1/2 x 1-1/2 x 1/4 | 2.34 | 46.80 |
| 2 x 2 x 1/8 | 1.65 | 33.00 |
| 2 x 2 x 3/16 | 2.44 | 48.80 |
| 2 x 2 x 1/4 | 3.19 | 63.80 |
| 2 x 2 x 3/8 | 4.70 | 94.00 |
| 2-1/2 x 2-1/2 x 3/16 | 3.07 | 61.40 |
| 2-1/2 x 2-1/2 x 1/4 | 4.10 | 82.00 |
| 3 x 3 x 1/4 | 4.90 | 98.00 |
| 4 x 4 x 1/4 | 6.60 | 132.00 |
| 4 x 4 x 3/8 | 9.80 | 196.00 |
Stainless Steel Angle Dimensions and Weight Chart
| Stainless Steel Angle Bar Sizes (all Dimensions in mm) | Approx Weight Stainless Steel Angle Bar (KG/Mtr) | Stainless Steel Angle Bar Sizes (all Dimensions in mm) | Approx Weight Stainless Steel Angle Bar (KG/Mtr) |
| 25 x 25 x 3 | 1.13 | 63 x 63 x 8 | 7.50 |
| 25 x 25 x 4 | 1.46 | 65 x 65 x 4 | 4.00 |
| 25 x 25 x 5 | 1.78 | 65 x 65x 5 | 5.02 |
| 30 x 30 x 3 | 1.37 | 65 x 65 x 8 | 7.75 |
| 30 x 30 x 4 | 1.78 | 70 x 70 x 5 | 5.35 |
| 30 x 30 x 5 | 2.20 | 70 x 70 x 6 | 6.40 |
| 40 x 40 x 3 | 1.83 | 75 x 75 x 6 | 6.85 |
| 40 x 40 x 4 | 2.41 | 75 x 75 x 8 | 9.05 |
| 40 x 40 x 5 | 2.97 | 80 x 80 x 6 | 7.35 |
| 50 x 50 x 4 | 3.05 | 80 x 80 x 8 | 9.65 |
| 50 x 50 x 5 | 3.78 | 80 x 80 x 10 | 11.98 |
| 63 x 63 x 4 | 3.90 | 100 x 100 x 8 | 12.20 |
| 63 x 63 x 5 | 3.90 | 100 x 100 x 12 | 18.00 |
Equivalent Grades Stainless Steel Angle
| STANDARD | SS 304 |
| WERKSTOFF NR. | 1.4301 |
| UNS | S30400 |
| JIS | SUS 304 |
| BS | 304S31 |
| GOST | 08X18H10 |
| AFNOR | Z7CN18-09 |
| EN | X5CrNi18-10 |
