SS 17-4PH Fasteners in Kentucky
SS 17-4PH Fasteners Supplier in Kentucky, SS 17-4PH Fasteners in Kentucky, ASTM A564 SS 17-4PH Stainless Steel Fasteners Stockist in Kentucky
Renine Metalloys is a leading SS 17-4PH Fasteners supplier and exporter in Kentucky. We supply industries with high-quality fasteners that provide strength, reliability, and performance in harsh environments.
SS 17-4PH fasteners are manufactured from a martensitic stainless steel alloy possessing high strength and corrosion resistance. These fasteners contain chromium, nickel, and copper, and acquire their mechanical properties due to precipitation hardening. After heat treatment, these fasteners offer a yield strength between 1,100 and 1,300 MPa and remain stable at temperatures up to 572°F (300°C). We supply these fasteners in customized sizes according to requirements. They meet ASTM, DIN, BS, GB, and IS industry standards.
Available in sizes from 3 mm to 200 mm, our SS 17-4PH fasteners come in various finishes like polished, mirror, and electroplated. These fasteners are manufactured as per ASTM A193, A194 and ASME SA193, SA194 specifications. We supply all major types, including bolts, nuts, screws, washers, studs, anchors, and sockets. Each piece is built to perform under high pressure and stress, making them ideal for aerospace, marine, chemical, and power generation sectors.
These fasteners are known for their excellent mechanical strength, durability, and resistance to wear and corrosion. When used in structural applications or high-heat setups, they withstand harsh conditions. The strength of SS 17-4PH makes them reliable even in tough industrial setups.
We are ISO-certified and ensure top quality. Our packaging is secure and weather-resistant. Every batch goes through hardness tests, tensile tests, impact tests, shell pressure tests, material inspections, and visual checks. We also provide complete documentation and test reports for full transparency. As a reliable SS 17-4PH Fasteners exporter in Kentucky, we ensure fast delivery, honest support, and technical help when needed.
SS 17-4PH Fasteners Specification
| Specifications | Details |
| Standard | ASTM A 193 / ASME SA 193 |
| Size | M3 – M100 | 3/6″ – 4″ | Custom Sizes |
| Fasteners Length | 3 mm – 200 mm | Custom Sizes |
| Nuts Size | M3 – M56 | 3/6″ to 2″ | Custom Sizes |
| Washers Size | M3 – M56 | 3/6″ to 2″ | Custom Sizes |
| Dimensions | DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3 |
| Threads available | UNF, BSW, BSF, METRIC, UNC, or as required |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Head | Hex, Square, Round, Hex flange, Flat, T-head & Triangular etc. |
| Neck type | Hex, Square, Triangular, Oval & Knurled etc. |
| Surface Coating | Black Oxide, Cadmium, Galvanized, Teflon, Xylan, Zinc, Others Upon Request |
| Manufacturing Process | Wire Drawing, Cold Heading, Insert tapping, Heat Treatment, Surface Plating, Inspection, Packing. |
Reach Out – We’re Happy to Help!
Feel Free to connect with us. Our team is ready for a handful of support
Types of SS 17-4PH Fasteners Kentucky
Bolt
SS 17-4PH Bolt in Kentucky
Nuts
SS 17-4PH Nut in Kentucky
Screw
SS 17-4PH Screws in Kentucky
Washer
SS 17-4PH washer in Kentucky
Stud Bolt
SS 17-4PH Stud Bolts in Kentucky
Anchor Bolt
SS 17-4PH Anchor Bolts in Kentucky
SS 17-4PH Fasteners Equivalent Grades in Kentucky
| STANDARD | WERKSTOFF NR. | UNS |
|---|---|---|
| SS 17-4 PH | 1.4542 | S17400 |
SS 17-4PH Fasteners Chemical Composition in Kentucky
| Grade | C | Cb+Ta | Cr | Cu | Fe | Mn | Ni | P | S | Si |
|---|---|---|---|---|---|---|---|---|---|---|
| SS 17-4 PH | 0.07 max | 0.15–0.45 | 15.00–17.50 | 3.00–5.00 | Bal | 1.0 max | 3.0–5.0 | 0.040 max | 0.030 max | 1.0 max |
SS 17-4PH Fasteners Mechanical Properties in Kentucky
| Grade | Tensile Strength | Yield Strength 0.2% | Elongation (%) | Hardness (Rockwell) Max |
|---|---|---|---|---|
| SS 17-4 PH | 170,000 psi (1172 MPa) | 140,000 psi (965 MPa) | 6% | 38 HRC |
